Note:-
- Any type of Internet connection you can use.
- Not required Static Public IP address.
Configuration of VPN Client:-
- Give IP address, subnet mask, gateway and DNS on your XP machine and check that Internet connection is properly working or not.
- Go to My Network Places Properties.
- Click on Create on new connection on Network Tasks.
- Select Connect to the network at my workplace and click on Next.
- Select Virtual Private Network connection and click on Next.
- Give Any connection name ( I am giving VPN) & click on Next.
- Give real IP address of your VPN server ( Static Public IP ) and click on next & Finish.
- Go to My Network Places properties.
- Go to Virtual Private Network properties.
- Go to Networking.
- Select Internet protocol (TCP/IP) and Click on Advanced.
- Remove Check mark from Use default gateway on remote network & click on O.K.
- Double click on VPN Dial-up connection and give user name & password which you have created on server then dial.
- Your VPN Client connection is configured successfully for testing it ping to your VPN Server.
Visit our Blog for VPN Server configuration on Windows 2003 Server.
